Planning And Development-Data Center

KLEF's state-of-the-art data center serves as the foundation for its digital operations and services. This facility houses critical infrastructure, including an HP cluster with high-performance servers and switches, supporting academic, research, and administrative functions, such as the university’s Enterprise Resource Planning (ERP) system. The data center is equipped with high-speed network connectivity and robust security protocols to ensure data integrity, availability, and confidentiality. With advanced virtualization technologies, the center enhances resource utilization and operational flexibility, facilitating efficient management of the university's computing resources.

HPC Cluster Image
  • Master Node:
    SR650 V2 (ThinkSystem) - Type 7Z73
    2 * Intel, ICX 633832C/2.0G/205W
    8 * 32GB TruDDR4 3200 MHz (2Rx4 1.2V) RDIMM
    2 * ThinkSystem 2.5" 5300 480GB Entry SATA 6Gb Hot Swap SSD
    14 * ThinkSystem 2.5" 5300 7.68TB Entry SATA 6Gb Hot Swap SSD
    Ethernet, Broadcom 57454, PCIe, 10GBASE-T, 4-port
    Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port x16 PCIe 3.0 HCA
    2 * Power Supply Delta 1100W 230Vac/115Vac AC Hot Swap

  • Compute Nodes:
    10 * SR630 V2 (ThinkSystem) - Type 7Z71
    2 * Intel, ICX 6338 32C/2.0G/205W
    16 * 16GB TruDDR4 3200 MHz (2Rx8 1.2V) RDIMM
    2 * ThinkSystem 2.5" S4610 240GB Mixed Use SATA 6Gb HS SSD
    Intel X550-T2 PCIe 10GbE Base-T Adapter
    Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port x16 PCIe 3.0 HCA
    2 * Power Supply Delta 1100W 230Vac/115Vac AC Hot Swap

  • Other Nodes:
    HP SL 230 4 * SL230s Gen8 (2 * 2.6 GHz, 32GB RAM, 2x500GB HD, 10G IB HCA)
    HP SL 250 2 * SL250s Gen8 (2 * 2.6 GHz, 32GB RAM, 2x500GB HD, 10G IB HCA)

  • GPU Node1:
    SR670 V2 (ThinkSystem) - Type 7Z23
    2 * Intel, ICX 633832C/2.0G/205W, 16 * 16GB TruDDR4 3200 MHz (2Rx8 1.2V) RDIMM
    2 * Nvidia, Ampere A40, PCIe, 48GB, 300W, FHFL, dual-slot, passive cooling, compute GPU
    2 * ThinkSystem 2.5" U.2 P5500 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD
    Intel X550-T2 PCIe 10GbE Base-T Adapter
    Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port x16 PCIe 3.0 HCA
    Power Supply Artesyn 1800W 230Vac AC HS

  • GPU Node2:
    SR670 V2 (ThinkSystem) - Type 7Z23
    2 * Intel, ICX 6338 32C/2.0G/205W
    16 * 16GB TruDDR4 3200 MHz (2Rx8 1.2V) RDIMM
    Nvidia, Ampere A30x
    ThinkSystem 2.5" U.2 P5500 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD
    Intel X550-T2 PCIe 10GbE Base-T Adapter
    Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port x16 PCIe 3.0 HCA
    4 * Power Supply Artesyn 1800W 230Vac AC HS

  • GPU Node3:
    R670 V2 (ThinkSystem) - Type 7Z23
    2 * Intel, ICX 6338 32C/2.0G/205W
    16 * 32GB TruDDR4 3200 MHz (2Rx4 1.2V) RDIMM
    4 * Nvidia A100 SXM4 500W 80GB HBMe GPU
    2 * ThinkSystem 2.5" U.2 P5500 3.84TB Read Intensive NVMe PCIe 4.0 x4 HS SSD
    Intel X550-T2 PCIe 10GbE Base-T Adapter
    Mellanox ConnectX-6 HDR100 IB/100GbE VPI 1-port x16 PCIe 3.0 HCA
    4 * Power Supply Artesyn 1800W 230Vac AC HS

  • IB Switch:
    Mellanox QM8790 HDR Unmanaged Switch PSE

  • Ethernet Switch:
    2 * Cisco Ethernet Switch 110 Business 24T

  • Software:
    Red Hat Enterprise Linux – 8.4
       Cluster Manager = LiCO 6.3
       Scheduler = SLURM - 20.11.7
       User Management = OpenLDAP

  • TERA Flops: 282.54 TERA Flops (CPU + GPU)
HPC Cluster Image

HPC Cluster-2

  • DELL MX 7000:
    Intel Xeon Gold 5117 2.0G, 14C/28T, 10.4GT/s, 19.25M Cache, Turbo, HT (105W)
    DDR4-2400, 32GB RDIMM 2666MT/s Dual Rank X2
    300GB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive

  • HPC CLUSTER-II:
    4 * HP SL230s Gen8 (2 * 2.6 GHz, 32GB RAM, 2x500GB HD, 10G IB HCA)
    2 * HP SL250s Gen8 (2 * 2.6 GHz, 32GB RAM, 2x500GB HD, 10G IB HCA)

  • Core Switch:
    HP 12508 (1250x G2 Fabric Module, HP 1250x G2 Fabric Module, HP 12500 16-port 10GbE SFP+ LEC Module, HP X130 10G SFP+ LC LR Transceiver, 6.12 Tbps (Calculation: 720 Gbps x Eight Line card slots + 180 Gbps x Two MPU slots)
HPC Cluster Image

HPC Cluster

  •  HP C7000 Blade Chassis C7000 (HP Cloud System Matrix Kit, 2* HP Virtual Connect Flex Fabric 10Gb 24-port Module redundant pair each module with 4* 10GB Uplinks and 4* 8Gbps Uplinks and with 4* FC cables, 1* Matrix Operating Environment)
  •  8* BL460c Gen8 Servers (BL460c Gen8, 2*E5-2665 8Core, 128GB (16* 8GB) Memory, 2*300GB 15K RPM SAS drives,1* HP Flex Fabric 10Gb 2-port 554FLB FIO Adapter).
HPC Cluster Image

Application Rack Server-1

  • 3* DL360e Gen 8 Intel(R) Xeon(R) CPU E5-2403 0@ 1.80GHz 1.80 GHz 16GB RAM.
  • 2* DELL POWER EDGE R240 Intel(R) Xeon(R) CPU E-2224@3.40 GHz 3.41 GHz 32Gb RAM
  • 2*TYRONE SDI100C2R-28
  • Dual Socket P+ (LGA-4189), 3rd Gen Intel® Xeon® Scalable processors, Support CPU TDP 270W, Intel® C621A 1Tb RAM, Storage (3*16TB SAS, 2*480GB SSD)
  • Think System SR550
  • Intel ® xeon® silver 4210 CPU@2.20 GHz 2.19 GHz,32Gb RAM, 2TB HDD
  • 2*Prolaint DL20 Gen10 Plus
  • Intel(R) xeon ® E-2314 CPU@2.80 GHz 2.81GHz, 32Gb RAM, 1TB HHD

  • Power Edge R660XS
  • IX SIL 4410Y 2G 4*32 7*12T NDSR POWER EDGE
  • Dell Power Edge R660XS
  • IX PLAT 8460Y + 2G 16*32 4*960 NDSR POWER EDGE

  • 3*Dell Power Edge R660XS
  • IX SIL 4410Y 2G 4*32 2*960NDSR POWER EDGE
HPC Cluster Image

ERP/LMS Server

  • HP PROLIANT DL 380 GEN 9 SFF 2:2 X 8 X 2 core Intel Xeon, 32 GB X 4 DDR4 ECC RAM
  • HP PROLIANT DL 380 GEN 9 SFF 2 : 2 X 8 X 2 core Intel Xeon, 32 GB X 4 DDR4 ECC RAM
  • PowerEdge MX740C Server : Intel Xeon Gold 5117 2.0G, 14C/28T, 10.4GT/s, 19.25M Cache, Turbo, HT (105W) DDR4-2400 , 32GB RDIMM 2666MT/s Dual Rank X2, 300GB 10K RPM SAS 12Gbps 512n 2.5in Hot-plug Hard Drive
  • HP DL 360 GEN 10 : 8 core Intel Xeon Bronze 3106 , 16 GB Ram, 600 GB HDD

LMS Servers :

  • HP PROLIANT DL 380 GEN 9 SFF 2:2 X 8 X 2 core Intel Xeon, 32 GB X 4 DDR4 ECC RAM
  • HP PROLIANT DL 380 GEN 9 SFF 2 : 2 X 8 X 2 core Intel Xeon, 32 GB X 4 DDR4 ECC RAM
HPC Cluster Image

Storage

    •  Unified Storage
    •  HP 3AR P7400 Storage (30*HP M6720 2TB 6G SAS 7.2K 3.5in NL HDD + 68 * HP M6710 300GB 6G SAS 15K 2.5in HDD + 8*HP M6720 100GB 6G SAS 3.5in SLC SSD)

    Tape Library :

    •  HP MSL4048 2* LTO5 FC drives and 48 Slots with RPS &Cloud System Matrix.

    BYOD :

    •  BYOD Servers& Backup Server
    •  HP DL360&HP IMC Standard Edition Software.

    Sun Servers:

    • Sun Fire X2250-2 No(s)
    • Intel Xeon 5472 (Quad Core 3.00GHz, 1600GHz FSB)
    • Main Memory 4*4GB- 16GB
    • Two hot- pluggable 3.5-inch SATA
    • Two on-board Intel 1Gb NICs
    • One TIA/EIA-232-F asynchronous RJ45 Port
    • Sun Integrated Lights Out Manager(ILOM)
    • Windows 2003(64-bit) Enterprise Editions

Apple Server Xserve:

  •  2 x 2 GHz Dual Core Xeon Processors
  •  6 GB RAM
  •  1333 MHz FSB
  •  750 GB SAS HDD
  •  Apple File Server
  •  Disk Monitor
  •  iSync
  •  PODCAST Server
  •  Quick Time Broadcaster

Storage & Backup:

  •  As –CX 300  EMC2  SAN Storage 3.0 Tera Bytes
  •  Apple SAS Storage 1.5 Tera Bytes‏
  •  AS-PV110T(LTO-3) Dell Power Value 110 T (LTO-3) Tape Drive
  • Internal 3.5 in. SATA disk drives 500 GB, RAID 0/1.
HPC Cluster Image

Network and Security

  • Firewall - Sophos XGS 8500
  • 8 x GE copper,12 x SFP+ 10 GE fiber*,2 x QSFP28 10/25/40/50/100 GE
  • RAM :256 GB DDR4 ECC 3200 + 24 GB DDR4 2667 ECC
  • Internal storage :2 x min. 960 GB NVMe SSD HW RAID built into CPU
  • Threat Protection throughput 92,500 Mbps
  • WirelessController (WLC) ARUBA 7220
  • WirelessController(WLC) Extreme NX5500
  • Wireless Controller (WLC) Ruckus SZ100
  • Core switch : HPE Aruba Networking 8325-32c 32p 100G QSFP+/QSFP28
  • Distribution switch 1 : HPE Aruba Networking CX 8100 48X10G SFP+ 4X40/100G QSFP28
  • Distribution switch 2 : HPE Aruba Networking CX 8100 48X10G SFP+ 4X40/100G QSFP28
HPC Cluster Image

High Speed Fiber Backbone

  • FIBER-LIU
  • High Speed Network Backbone Media
    • Software:

    K L Deemed to be University has latest software for academic and research programs.

    • Microsoft Open Value Subscription
    • Microsoft Office 365, Students & Faculty
    • Microsoft Dreamspark
    • CentOS, Ubuntu, Fedora, Redhat Linux version 9.0 professional
    • Career development software.
    • IBM suite.
    • MATLAB (Simlink, Fuzzy logic, Image processing, Neural networks, Signal processing).
    • Oracle 8.1.7 and Oracle 10.2.1 g.
    • Oracle Primavera
    • Auto Civil
    • STAAD PRO
    • ANSYS University High
    • ORCAD PSPICE
    • Sigma Plot
    • PSPICE Cadence
    • XILINIX ISE Design Suit
    • VHDL (XILINIX6, modelsim)
    • Pro-E wild fire
    • Brics CAD
    • Autodesk Maya 2011
    • Autodesk Mechanical Desktop, Autodesk Maya 2011
    • Autodesk Inventor Series
    • Autodesk Architectural Desktop
    • IBM IDEAS
    • IBM-CATIA
    • Discrete 3DS Max
    • CIM Simulation
    • ESpirit Cam
    • Build Master
    • Mi Power
    • ETAP
    • PSCAD
    • Hyper works (Altair) with site license for 22 modules.
    • ESRI Arc GIS Desktop
    • CADENCE
    • MSC ADAMS
    • MSC NASTRAN
    • MAS PATRAN
    Computer Networking

    Campus wide network has been established with hi speed fiber optic back bone.

    • 20 Gbps ILL + 1Gbps NKN Internet connectivity
    • Round the clock Internet connectivity
    • Total Wi–Fi (AC/B/G/N) enabled campus.
    • E-learning facilities
    • 3128 computers are installed in various computer centers across the university which are open from 7AM - 10PM.
    • All the faculty are mandated to carry Laptops / Tablets to the class rooms and students are encouraged to used laptops in class.
